Heavy Duty Trash Pumps

SKU: SPTP50HX

PRICE: $1,999.00 (inc GST)

Honda engine driven trash pumps manufactured by Paddock Machinery. Heavy duty design for dirty water operation. Suited to building and construction sites for pumping out pits, basements and sumps. High quality Japanese construction suited to the harsh Australian environment.

Heavy Duty Honda Engine Driven Trash Pumps

  • Suited to sludge, sewage and services with high solids loading
  • High chrome cast impeller
  • Wear resistant pump liner
  • Genuine Honda GX commercial engines
  • Steel roll-over cage protection
  • Easy clean and maintenance design

Pump Details:

These are a trash style of pump suited for pumping waters with higher then typical solids loading. This style of pump is ideal for applications where the quality of water can not always be guaranteed and is commonly used in construction, mining and flood mitigation applications. These pumps are built with heavier wetted components to resist wear and feature a quick access casing design for clean out.

Manufactured in Japan, these pumps are built to the highest quality standard and are garanteeded to perform. The pump castings are thicker, stronger and better designed then others in the market. The pump casing has a wear resistant liner and the impeller is manufactured from a high chrome cast iron. The silicon carbide mechanical seal ensures leak free perfromance.

Refer to the tables below for the full specifications on this range of quality built trash pumps.

Engine Details:

Honda GX commercial engine

The Honda GX series of 4-stroke commercial engines are world renown for being workhorse engines with extreme reliability. Honda engines are always easy to start and are very well supported with Honda dealers and spare parts kept in every corner of the continent. For a ultimate in reliability stick with the Honda GX series of engines.

Specifications SPTP50HX SPTP80HX SPTP100HX
Pump Inlet / Outlet 2" / 2" 3" / 3" 4" / 4"
Max. Flow (L/min) 600 1,300 2,000
Max. Total Head 26 m 28 m 24 m
Max. Suction Head 8 m 8 m 8 m
Solids Handling Capacity 20 mm 31 mm 31 mm
Honda Engine GX160 GX240 GX340
Engine Type  4-Stroke Commercial Series
Engine Power 4.9 hp 8 hp 10.9 hp
Fuel  Unleaded Petrol
Fuel Tank  3.1 L 5.3 L 6.1 L
Starter  Recoil
Weight 35 kg L 53 kg 73 kg
Dimensions 560 x 436 x 397mm 672 x 485 x 610mm 730 x 484 x 610mm
Wetted materials

SIC Mechanical seals

HI-CHROME Cast iron impeller

Aluminium pump casing with liner

Inclusions Hose couplings, strainer and clamps
Warranty  3 yrs
Manufactured Japan
