Agriculture & Farming

Silage Wrappers

SKU: PHBWRPELE

PRICE: $4,999.00 (inc GST)

The Paddock Machinery range of mini silage bale wrappers are second to none. Available with either a 240V electric drive or genuine Honda 4-stroke engine. Make your own silage bales with ease. Ideal for small farms and acreages where hay has a higher water content and than is suitable for traditional dry hay baling techniques. Compatible with the Paddock range of mini hay balers and silage film as well as other brands. Packed with features and built to last these round bale wrappers will not disappoint.

Round Bale Silage Film Wrappers

  • Make your own silage!
  • Available in electric or Honda engine drive
  • Made to last! Heavy duty construction
  • Portable (Honda GX160 model)



Silage Bale Wrapper Set Up

The electric silage wrapper can be fitted with a standard power lead or hard wired. No special outlets are required as it's standard 240V with a current drawer of just over 4 amps. Set up on a level, firm, indoor surface and you're good to go. The Honda powered wrapper is portable and can be used outdoors (although should not be left exposed to the rain or elements). It comes with two screw out levelling legs to keep the machine balanced.

Easy to Operate

These silage wrappers are easy to operate. Load the film onto the holder and feed through the tensioner, lay some film onto the roller bed and load on a bale. Start the machine by pressing the start button on the electric model or by engaging the clutch lever on the Honda model. The wrapping counters will ensure you've wrapped the silage bale sufficiently.

Silage Wrapper Maintenance

The Paddock mini silage wrapper is built to be low maintenance. It's understood most owners / operators will be in remote or rural areas and it's not always convenient to take equipment in for a service. The wrapper can be easily serviced by anyone with a few mechanical skills. Maintenance includes tasks such as greasing nipples, oiling chains, tensioning belts and for the Honda model the occasional oil change. See the user manual for the Maintenance Schedule and requirements.

Service & Parts

Paddock Machinery carries a full range of spares and replacement parts for the round bale silage wrappers through their Australian office and product support is only a click away!

Silage Wrappers
Electric (PHBWRPELE)
Honda (PHBWRPHON)
Drive Type
Electric 240V 50Hz
Honda GX160 4-Stroke Petrol Engine
Power 550W 4.8 hp (3.6 kW) @ 3,600 rpm
Bale Size up to 700mm (D) x 800mm (H)
up to 700mm (D) x 800mm (H)
Production Capacity up to 120 bales / hour up to 120 bales / hour
Dimensions 830mm (W)x 1500mm (L) x 1070mm (H) 1180mm (W) x 1600mm (L) x 1080mm (H)
Wheels 150mm Diameter 230mm Diameter
Construction

40mm Square tube

3mm thick steel

Black enamel coating

40mm Square tube

3mm thick steel

Black enamel coating

Features

Oil filled reduction gearbox

Electrical wrap control (set the number of wraps)

Direct chain drive to the rollers

Spring tensioned film holder

Twin belt drive

Lever engaged friction clutch for smooth operation

Analogue wrap counter

Direct chain drive to the rollers

Spring tensioned film holder

Level adjusters for in field balancing.

Certification CE Certified, ISO9001:2000 CE Certified, ISO9001:2000
IP Rating IP55 IP55
Warranty 2 Years

2 Years
